About these items
This 2 HP electric motor offers an ideal combination of power and efficiency for industrial and domestic applications. It operates on 115 V or 230 V AC, supporting a load of 20.5 A or 10.5 A, ideal for environments requiring high starting torque at 1725 RPM.
Its structure features a robust 143/5T frame and a 7/8" shaft with a 2.25" length and a 0.188" keyway, key features for stable and efficient transmission of mechanical power.
The dual CW/CCW rotation design facilitates flexible installation, reducing connection times and adapting to different wiring configurations and rotation directions.
The motor housing is made of rolled steel, providing robust mechanical protection. It includes a thermal protection system with manual reset that prolongs operation and helps prevent overload failures.
Compatible with a wide range of applications, this motor is suitable for water pumps, agricultural tools, compressors, and a variety of general equipment. Its universal capacity makes it ideal for both workshops and DIY enthusiasts.
Key Differences
This model offers 2 HP with single-phase power at 115 V or 230 V, standing out for its 143/5T frame and a longer 7/8" shaft. (2.25") compared to other similar motors. It is designed to offer greater strength and adaptability in demanding installations and features a thermal protection system that improves motor durability under prolonged use.
Specifications
Item model number: SY-2HP-4P-B3-C
Voltage: AC 115V/230V
Frequency: 60Hz
Horsepower: 2.0 HP
Current: 20.5A / 10.5A
Frame size: 143/5T
Rotation speed: 1725 RPM
Net weight: 20.0 kg
Dimensions: 360 x 230 x 210 mm (14.2 x 9.1 x 8.3")
Package Contents
1 x User Manual
Product Details
| Color |
1725 RPM 2.0 HP |
| Power Supply |
Hard-Wired (AC power) |
| SKU |
sr25090358661866346 |
